Prepare Document Knowledge Base

Parse and chunk manuals, reports, and other material into a knowledge base, while saving parsed files and source relationships. After processing, retrieve document content from the knowledge base and inspect the saved files.

This template builds a text index. For page or document-image retrieval, use Prepare Document Knowledge Base with Image Index. For engineering drawings, use Drawing Parsing.

Prepare your resources

Resource	What to prepare
Source files	Upload material to a Catalog volume. Start with a familiar PDF or Word manual so you can check the results
Knowledge base	Select an existing knowledge base or create one during configuration; it supplies the text index table and embedding model
Output location	A Catalog volume or directory for parsed results

Check the source and destination separately so saved results are easy to locate. For audio or video, use the speech or video template.

Load the template

1. Select Start from a template on the workflow creation page.

2. Search for Prepare Document Knowledge Base and load it onto the canvas.

3. Review the processing steps, then fill in the run parameters.

The screenshot shows the template selection entry in the Chinese interface.

Understand the processing steps

The diagram follows the template’s execution order. Each box describes its data; arrows show sequencing.

1. Read MOI Volume selects files and obtains source references and original file IDs.

2. General Document Parsing reads files into records containing content and source metadata.

3. Segment splits parsed documents into chunks for indexing.

4. Embed and Add to Knowledge Base generates chunk vectors and writes them to the selected index table.

5. Write Document Files writes parsed records to files used for lineage registration.

6. Save to MOI Volume saves parsed documents at the chosen destination.

7. Lineage Registration records relationships among originals, parsed artifacts, saved results, and the text index.

Indexing uses chunks; file-writing steps use the parsed documents before chunking. Downloaded record counts can therefore differ from chunk counts and index row counts.

The template supplies these bindings. When editing nodes, retain separate references to parsed and chunked documents so saving does not accidentally use another intermediate output. See Variables and data flow.

Configure processing

Select sources and destinations

Setting	What to select
Source files	Files or a volume; check scope and types when selecting a whole volume
Parsing tier	Required; defaults to Standard
Knowledge base	Select or create the text-index destination and check its embedding model
Output location	Volume or directory receiving parsed results

When reading a volume, filter by file type if needed. To inspect part of a document, set a page range such as 1-3. Pages start at 1; leaving the range empty processes all pages.

Choose a parsing method

Material	Suggested configuration
Ordinary manuals and reports	Start with Standard and inspect text and tables
Office documents with native text and structure	Try Native and check that the required structure is retained
Scans, complex tables, formulas, or multiple columns	Use Enhanced and adjust table, image, and reading-order options

See General Document Parsing for enhanced settings. Check parsed content before deciding whether chunking needs adjustment.

Adjust chunking and indexing

These defaults apply to this template.

Setting	Default	Purpose and adjustment
Chunk size	512	Target character length for splittable text. Try larger chunks if context is missing, or smaller chunks if unrelated topics are combined
Overlap	50	Characters repeated between adjacent chunks. Check context across boundaries; must be at least 0 and less than chunk size
Three-level index (doc/section/chunk)	Enabled	Builds document, section, and chunk records
Section size	5	Consecutive chunks per section when three-level indexing is enabled

Length is measured in characters, not model tokens. Tables and code blocks retain their structure and can exceed the target length. See Segment and Embed and Add to Knowledge Base.

Run and inspect results

1. Save parameters and start a manual run. The system saves the workflow before submitting execution. If parameters are missing, complete and save the form, then run again.

2. Open the run record and check the reading node’s file count against the intended scope.

3. Compare parsed content and source metadata with the original, including headings, tables, and key passages.

4. Inspect chunk boundaries, overlapping context, and source metadata.

5. Check the index node’s target table and written count.

6. Open the output location to inspect saved files. Check the final lineage result when tracing sources.

7. Retrieve known content from the knowledge base and confirm that it comes from the expected file.

What each result means

Location	What to inspect
Parsing node	documents contains parsed records; plain_text helps inspect content
Segment node	documents contains chunks with source metadata
Knowledge base writing node	written counts actual index rows across enabled levels, not files or just chunks
File-writing and saving nodes	file_id identifies the primary file; file_ids covers all results. Multiple sources may produce several files
Lineage node	Confirm that source, parsed, and index assets match this run

The output-saving step is configured for ZIP. The document-writing step’s format also depends on artifacts: ordinary records can produce JSONL, while associated parsing artifacts can produce ZIP. Inspect the actual list and formats; see Write Document Files.

Example: prepare a product manual

For a manual containing section headings and parameter tables:

1. Select the manual, a product knowledge base, and an output volume.

2. Keep Standard parsing, chunk size 512, overlap 50, three-level indexing, and section size 5.

3. Run the workflow and compare one complete section and one parameter table with the original.

4. Test retrieval with a question answered in the manual, such as a parameter’s allowed range, and verify the returned content.

5. If a table is incomplete, adjust Enhanced table settings and compare results using the same input.

Before rerunning, confirm the knowledge base and destination and decide which existing results need to be retained. Check relevant node settings for overwrite or duplicate writes.

Common problems

Symptom	What to check
Unwanted files were processed	Review source selection and file-type filtering, then check the reading node’s count
Missing table content or incorrect reading order	Compare parsed output with the original; use Enhanced and adjust table or reading-order options as needed
Retrieved chunks lack context	Confirm parsing is complete, then inspect chunk boundaries, overlap, and multi-level indexing
More index rows than files	Three-level indexing creates several kinds of records; compare with chunks rather than file count alone
Saved files cannot be found	Check whether saving completed, verify the destination, and inspect all file_ids
Indexing succeeded but the workflow failed	Inspect later writing, saving, or lineage errors; check already written results before rerunning
Images themselves need to be retrieved	Use the image-index template and configure its model and index

For further troubleshooting, see Run and debug.
